1. Introduction to GH2132 Materials
GH2132 is an Fe-25Ni-15Cr base superalloy strengthened by molybdenum, titanium, aluminum, vanadium and trace boron. It features high yield strength, rupture strength and creep strength below 650℃, excellent hot/cold workability and satisfactory weldability. It is widely used for long-term high-temperature load-bearing aero-engine components working under 650℃, such as turbine disks, compressor disks, rotor blades and fasteners.
2. Chemical composition of GH2132
| Alloy | Limit | Ni | Cr | Fe | B | Mo | V | C | Mn | Si | S | P | Cu | Al | Ti |
| GH2132 | Minimum | 24 | 13.5 | Bal | 0.003 | 1 | 0.1 | – | – | – | – | – | – | – | 1.9 |
| Maximum | 27 | 16 | 0.01 | 1.5 | 0.5 | 0.08 | 0.35 | 0.35 | 0.002 | 0.015 | 0.3 | 0.35 | 2.35 |
3. GH2132 physical properties
| Density(g/cm³) | Melting point(℃) | Thermal conductivity(W/m·℃) | Specific heat capacity(J/kg·℃) | Elastic modulus(GPa) | Shear modulus(GPa) | Resistivity(μΩ·m) | Linear expansion coefficient(10⁻⁶/℃) |
| 7.99 | 1364-1424 | 14.2(100℃) | – | – | – | 0.914 | 15.7(20~100℃) |
GH2132 mechanical properties: Minimum values tested at 20℃
| Alloy state | Tensile strength Rm N/mm² | Yield strength RP0.2 N/mm² | Elongation A5 % | Brinell hardness HB |
| Solid solution state | 930 | 590 | 15 | ≤341 |
Heat treatment requirements
| Material variety | Heat treatment system |
| Bars, round billets | 980~1000℃, 1~2h, oil cooling +700~720℃, 12~16h, air cooling |
| Hot rolled plate, cold rolled plate | 980~1000℃, air cooling +700~720℃, 16h, air cooling |
| Cold drawn bar | 980~1000℃, 1~2h, oil cooling +700~720℃, 16h, air cooling |
| Ring blank | 980~990℃, 1~2h, oil cooling +700~720℃, 15h, air cooling |
| Cold drawing stock for cold heading | 980~1000℃, 1~2h, water/oil cooling +700~720℃, 16h, air cooling |
4. GH2132 production implementation standards
| Standard category | Chemical composition | Bar | Forging | Plate | Wire | Tube | Ring forging |
| National Standards | GB/T14992 | GB/T14994 GB/T14993 |
GB/T14997 GB/T14998 | GB/T14995 GB/T14996 |
– | GB/T15062 | – |
| Aviation industry standards | – | HB5189 | – | – | – | – | – |
| National Military Standards | – | GJB2611 GJB3165 |
– | GJB3317 | GJB2612 GJB3167 |
– | GJB3020 GJB3782 |
5. GH2132 application fields
Application overview & requirements: In aviation industry, it is mainly used for engine compressor disks, turbine disks, load-bearing rings, casings, shafts, fasteners and plate welded load-bearing parts operating below 650℃, and has been widely applied in domestic aerospace manufacturing.
