Scope of supply of Aviation Group:
It can be customized non-standard, aluminum plate (whole plate/cut), aluminum rod, aluminum forgings, aluminum tubes, aluminum profiles, etc. Welcome to inquire!
1. Introduction to 5754 Materials
5754 is AL-MG anti-rust aluminum, with medium strength, good corrosion resistance, welding and easy processing and forming characteristics. It is a typical alloy among Al-Mg alloys. In foreign countries, 5754 with different heat treatment states are the main materials used in the automobile manufacturing industry (car doors, molds, seals) and canning industry.
2. 5754 Chemical Composition
| Alloy Medal | Silicon Si | Iron Fe | Copper Cu | Manganese Mn | Magnesium Mg | Chromium Cr | Zinc Zn | Titanium Ti | other | Aluminum AL | ||
| New grade | Old brand | 0.40 | 0.40 | 0.10 | 0.50 | 2.6-3.6 | 0.30 | 0.20 | 0.15 | Each | total | Remain
quantity |
| 5754 | – | 0.05 | 0.15 | |||||||||
3. 5754 Physical properties
| Aluminum alloy grade and status | tensile strength
Rm/Mpa |
Yield of yield
Rp0.2/Mpa |
Elongation/% | Hardness/HBWα | density
(20℃) (g/cm3) |
| 5754-O | 190-240 | 80 | 12 | 38 | 2.75 |
IV. 5754 application fields
5754 is widely used in automotive parts, welding structures, storage tanks, pressure vessels, trains, ship structures and offshore facilities, transportation tanks, and occasions where excellent processing performance, excellent corrosion resistance, high fatigue strength, high welding ability and medium static strength are required.
